Connect a twisted pair wire from A+ on the USB converter to "RS-485 A" on up to 256 EKM Meters, connect B- to "RS485 B" on the same meters.įor more information about our products and services, we encourage you to visit our online Knowledge Base, which provides spec sheets, videos, tutorials, FAQs, diagrams, and more.
#Usb 485 converter con drivers#
Be sure that you have the FTDI USB Drivers installed. These are very easy to connect and wire up (requires a tiny 2mm flat head screwdriver). Works with all of our RS-485 smart meters including our v.3 Omnimeters and the v.4 Omnimeter Pulse. Works with most modern (macOS, Windows, Linux) operating systems.Ĭheck out this Communication Diagram showing an example of the USB Converter connected to multiple Omnimeters (up to 256 meters).
#Usb 485 converter con install#
In order to use this converter please download and install the USB driver. This is shown with a red blinking LED bulb, that flashes as successful reads are made. This new model of USB Converter has a transparent case, which allows it to show a visual indication of successful meter reads. The terminal blocks are tiny, so we include a small screwdriver with each USB Converter so that they can be opened and closed more easily.
This converter uses a chip that is manufactured by FTDI, which is much more robust, reliable, and easier to use than competing chips. We especially recommend it for users of the EKM Push system which cannot yet make meter settings. It is really handy for making meter settings (in particular) and for reading your meters directly.
We recommend this USB converter to all customers who purchase any of our v.3 Omnimeters or v.4 Omnimeters. You can connect up to 256 meters on 4000 feet of twisted pair wire to this converter. This is an inexpensive device that will work well if you want to read your meters locally (on-site). Our USB Converter, translates the RS-485 signal from the meters to a signal that can be understood by your computer and our EKM Dash software. Advantages: Easy to install, easy to use, and blinks when active.
